1- 1 Channel 12V Relay Module Board Shield Optocoupler Support Low
$26.31
Sale price
$26.31
Regular price
$32.60
Shipping calculated at checkout.
Discover the 1- 1 Channel 12V Relay Module Board Shield Optocoupler Support Low, a standout decor pick designed for dependable everyday performance and lasting value.
Specifications
Brand Name: Aideepen
EU LVD Voltage: Low voltage: Below 50Vac or 75Vdc
is_customized: no
Product Features
1. Utilizes bidirectional optocoupler isolation for robust drive capability and stable performance.
2. Module supports high-level or low-level trigger configuration via jumper settings.
3. Features four fixed mounting bolt holes.
4. Includes power indicator LED (red).
5. User-friendly interface design with all connections accessible via direct wiring terminals.
Product Parameters
Trigger Current: 5mA
Module Operating Voltage: DC12V
Load Current: 2A
Module Dimensions: 50mm × 26mm × 18.5mm (L × W × H)
Features four mounting bolt holes: 3.1mm diameter, 44.5mm × 20.5mm spacing
Module Interfaces
DC+: Connect to power supply positive terminal (voltage per relay requirements)
DC-: Connect to power supply negative terminal
IN: Controls relay engagement via high or low level signal
Relay Output Terminals:
NO: Relay normally open terminal. Floats open before engagement; shorted to COM after engagement.
COM: Relay common terminal
NC: Relay normally closed interface, shorted to COM before relay engagement, left floating after engagement
High/Low Level Trigger Selection Pin
1. When jumper is shorted to LOW, low-level trigger is enabled;
2. When jumper is shorted to HIGH, high-level trigger is enabled.
Shipping List
Relay Module*1
Options
- Size: 10pcs, 5pcs, 1pcs
