11kV–35kV Outdoor High-Voltage Cable Distribution Box 630A

11kV / 24kV / 35kV European-Style Fully Insulated Cable Branch Box – 630A

Meet the demands of modern medium-voltage infrastructure with this heavy-duty European-style Outdoor High-Voltage Cable Distribution Box. Designed for 11kV, 24kV, and 35kV networks, this fully insulated cable branch box delivers dependable power distribution in utility, commercial, and industrial outdoor environments — rated at a robust 630A continuous current.

Built to European electrical standards, the fully insulated enclosure ensures safe, weatherproof operation in demanding outdoor conditions. Its compact, modular footprint simplifies installation and integration into existing medium-voltage cable networks, making it the go-to solution for electrical engineers and infrastructure contractors.

Made in Mainland China.

Key Features

• Multi-Voltage Rating: Compatible with 11kV, 24kV, and 35kV network voltages — one platform for multiple grid tiers.
• 630A Rated Current: High current capacity to support demanding distribution loads.
• Fully Insulated Design: European-style full insulation eliminates exposed live parts for enhanced operator safety.
• Outdoor-Ready Enclosure: Weatherproof, corrosion-resistant housing engineered for sustained outdoor deployment.
• Modular Size Options: Available in six enclosure sizes to suit varying cable configurations and installation space requirements.
• Cable Branch Flexibility: Supports multiple cable branch connections for grid loop and ring-main applications.
• Low Maintenance: Sealed, maintenance-friendly construction reduces downtime and operational costs.

Available Enclosure Dimensions (W × D × H mm)

1. 640 × 600 × 1000 mm
2. 740 × 600 × 1000 mm
3. 840 × 600 × 1000 mm
4. 940 × 600 × 1000 mm
5. 1040 × 600 × 1000 mm
6. 1140 × 600 × 1000 mm

Select the enclosure size that best accommodates your cable count and installation requirements. Contact us if you need assistance matching a size to your project specifications.

Specifications Summary

Applications

• Urban and suburban medium-voltage cable networks
• Industrial facility power distribution
• Utility substations and ring-main cable systems
• Commercial campus and infrastructure electrical installations
• Renewable energy site medium-voltage cabling

Related Products

You may also be interested in these items from our store:

• 1-Channel Relay Module DC 3.3V–24V Optocoupler for Arduino
• 1-Channel SCR Solid State Relay Module DC3-24V 40A Optocoupler

External Reference

For guidance on electrical safety standards and practices relevant to high-voltage distribution equipment, refer to the OSHA Electrical Safety Standards.

Frequently Asked Questions

Q: What voltage levels is this cable distribution box compatible with?

A: This European-style cable branch box is rated for 11kV, 24kV, and 35kV medium-voltage networks, making it suitable for a wide range of utility, commercial, and industrial grid applications.

Q: What does "fully insulated" mean for this high-voltage distribution box?

A: "Fully insulated" means all live conductive components within the enclosure are completely covered with insulating material, eliminating exposed energized surfaces. This European design approach significantly enhances operator safety and reduces the risk of accidental contact with live parts during inspection or maintenance activities.

Q: Which enclosure size should I choose?

A: The right size depends on the number of cable branches and the physical space available at your installation site. Widths range from 640mm to 1140mm (all at 600mm depth × 1000mm height). If you need help selecting the correct configuration for your project, please contact our technical support team before ordering.

Q: Is this distribution box suitable for outdoor installation?

A: Yes. The enclosure is specifically engineered for outdoor deployment, featuring a weatherproof and corrosion-resistant housing designed to operate reliably in varying environmental conditions including rain, humidity, and temperature fluctuations.

Q: What is the maximum current rating of this cable branch box?

A: This unit is rated at 630A continuous current, providing ample capacity for demanding medium-voltage distribution loads in both loop and radial network configurations.
