5-Pack T5 T8 Non-Shunted Tombstone Lamp Socket G5 G13 Base

5-Pack T5 & T8 Non-Shunted Tombstone Lamp Sockets – G5 & G13 Base

Upgrade or replace worn-out fluorescent tube holders with these reliable, high-quality T5/T8 lamp sockets. Rated at AC 500V / 2A, these non-shunted tombstone sockets are engineered for direct LED tube conversions and standard fluorescent tube fixtures, ensuring a secure, stable connection every time.

Made in Mainland China.

Why Choose These Lamp Holders?

• Universal Compatibility: Fits both G5-base T5 tubes and G13-base T8 tubes – one pack covers two common tube types.
• Non-Shunted Design: Ideal for single-pin LED tube replacements that require separate, non-connected contacts for correct wiring.
• High Voltage Rating: Rated AC 500V / 2A for safe, dependable performance in residential and commercial lighting fixtures.
• Durable ABS Construction: Made from tough, heat-resistant ABS plastic for long-lasting use in a variety of fixture types.
• Wide Application: Suitable for grille lamps, bracket lights, clean-room fixtures, and any straight-tube fluorescent or LED tube installation.
• Easy Installation: Simple drop-in replacement – no special tools required. Swap out damaged or old sockets quickly and easily.
• White Finish: Clean white colour blends seamlessly into ceilings and fixture bodies.

Specifications

Related Products You May Like

• 1-Channel SCR Solid State Relay Module DC3-24V 40A Optocoupler
• 1.8M DisplayPort to HDMI Cable 4K – DP Adapter for PC & TV

Safety & Standards Reference

For guidance on electrical safety and best practices when working with lighting fixtures and wiring, refer to the U.S. Consumer Product Safety Commission (CPSC).

Note: Slight dimensional variations may occur due to manual measurement. Actual colour may vary slightly from images depending on your monitor settings.

Learn more: AC power plugs and sockets

Frequently Asked Questions

Q: What is a non-shunted tombstone lamp socket and why does it matter for LED tubes?

A: A non-shunted tombstone socket has two electrically separate contacts in each end cap, allowing current to enter and exit independently. This design is required for single-ended or direct-wire LED tube replacements, where each pin on the tube carries a different wire (live/neutral). Using a shunted socket with these LED tubes can cause the tube to fail or not light up at all, so always confirm your LED tube type before choosing your socket.

Q: Are these sockets compatible with both T5 and T8 LED tubes?

A: Yes! This 5-pack includes sockets for both T5 tubes (G5 base) and T8 tubes (G13 base). Check the tube end-pin spacing on your fixture — T5 tubes use a 2-pin G5 base with a 5 mm pin gap, while T8 tubes use a G13 base with a 13 mm pin gap. The pack works across grille lamps, bracket fixtures, clean-room lights, and other straight-tube fluorescent or LED tube applications.

Q: How do I install these lamp holders in my fixture?

A: Always turn off and disconnect power to the fixture before starting. Remove the old or damaged socket by releasing any clips or screws holding it in place, then disconnect the wires. Connect the appropriate wires to the new socket's terminals, snap or screw the holder into position, insert the tube, and restore power. If you are unfamiliar with electrical wiring, we recommend consulting a qualified electrician.

Q: What fixtures are these tombstone sockets suitable for?

A: These sockets are suitable for a wide range of straight fluorescent and LED tube fixtures, including grille lamps, stent/bracket lights, clean-room lights, strip lights, and other commercial or residential fixtures that use T5 or T8 straight tubes.
