5V 9V 12V UPS 3 18650 Lithium Battery Soldering Surveillance Camera
Default Title
$21.83
Sale price
$21.83
Regular price
$27.04
Skip to product information
5V 9V 12V UPS 3 18650 Lithium Battery Soldering Surveillance Camera
$21.83
Sale price
$21.83
Regular price
$27.04
Shipping calculated at checkout.
Discover the 5V 9V 12V UPS 3 18650 Lithium Battery Soldering Surveillance Camera — a standout decor pick featuring compact design for dependable, everyday performance.
Specifications
Brand Name: Aideepen
Condition: New
Type: Module
Description:
1. Solder-free design allows users to freely disassemble and replace batteries
2. Features DC equalization UPS functionality for automatic charge/discharge management without manual intervention
3. Supports common voltages of 5V, 9V, and 12V for devices like optical modems, routers, and surveillance cameras
4. Rigorous quality control ensures long-term stable operation and extended service life
5. Compact size for easy portability with stable performance
Product Specifications:
Capacity: Battery compartment capacity: 3*3.7V*3400mAh = 37Wh (Batteries not included)
Output Power: Without considering UPS input, independent output of 12V 3A, 9V 1A, USB 5V 2-3A
Voltage Regulation: Unregulated; 3 batteries in series for direct output. Full charge at 12.6V, low voltage protection at 8V. Voltage fluctuates with remaining charge.
Application Type: Specifically designed for MODEMs, routers, and surveillance cameras
Battery Type: 3.7V cylindrical 18650 battery
UPS Input Voltage: Charges within 12-13V range; must not exceed 13V. Below 12.6V prevents full charge. Recommended: 12.7V
UPS Input Power: Input adapter power must meet ≥ load power + internal battery charging power (6W); higher power ensures greater stability
Protection circuit parameters:
Overcharge protection: 4.25V*3
Undervoltage protection: 2.75V*3
Overcurrent detection voltage: 0.1V ± 0.025V
Operating temperature range: -20~60℃
DC interface standard: DC5.5*2.1mm (positive inner, negative outer)
Important Notes:
1. Connect the spring to the negative terminal and the copper plate to the positive terminal. Do not reverse polarity, as doing so will cause burnout!!!
2. Use high-quality batteries and ensure strict pairing. Each individual cell in the battery pack must have as consistent parameters as possible.
3. This product is only compatible with flat-top 18650 batteries. Pointed-top batteries longer than 2mm cannot be used.
Package Contents:
Solderless Battery Case*1
