AD584 4-Channel Voltage Reference Module | Multimeter Calibration

AD584 High Precision 4-Channel Voltage Reference Module

The AD584 Programmable Voltage Reference Module is a compact, high-accuracy calibration tool designed for engineers, technicians, and electronics enthusiasts. Delivering four stable output voltages — 2.5V, 5V, 7.5V, and 10V — this module is the ideal reference source for calibrating multimeters, testing DAC/ADC converters, and verifying precision instruments. Made in Mainland China.

Key Features

• Four Selectable Output Voltages: Easily program your desired reference voltage (2.5V, 5V, 7.5V, or 10V) by short-circuiting the corresponding terminal block — no complex setup required.
• Stable, Low-Noise Output: The onboard 15V battery provides a low-noise power source, ensuring rock-steady voltage output for dependable, repeatable results every time.
• Parallel Terminal Design: Two programming terminals are connected in parallel to minimise the influence of short-circuit resistance on the output voltage, improving overall output accuracy.
• Ultra-Low Power Consumption: With a quiescent current of just 1 mA (maximum), this module is highly efficient and well-suited for battery-powered measurement setups.
• Wide Input Voltage Range: Operates from 4.5V to 30V DC input (external power must exceed 11V DC for proper operation).
• 2mm Copper Test Sockets: The reference voltage output interface features 2mm copper test sockets, making it quick and easy to connect a pen-type multimeter for calibration.
• Factory Tested: Every board is individually tested using an Agilent 6-digit multimeter before shipment, with the measured output voltage clearly marked for user convenience.
• Improved Reliability: Substituted switch terminals offer enhanced reliability, greater flexibility, and support for smaller short-circuit resistors — optimising module performance.

Specifications

What's in the Box

• 1 × AD584 Voltage Reference Module Board

Usage Tips

For best accuracy, allow the module to warm up at room temperature (25°C / 77°F) for at least 30 minutes before taking measurements or performing calibration. This ensures thermal stability and maximum output precision.

The AD584 chip is recommended as an external reference for 12-bit and 14-bit DAC/ADC converters, frequently outperforming standard standalone references in precision applications.
