KSZ115 Zero-Point Quick-Change Pallet Clamping System for CNC

KSZ115 Heavy-Duty Zero-Point Clamping System for CNC Machine Centers

Maximize your CNC machining efficiency with the KSZ115 Quick-Change Pallet Zero-Point Clamping System. Engineered for precision and repeatability, this heavy-duty clamping system eliminates time-consuming setups by allowing near-instant pallet changeovers with sub-micron positional accuracy. Whether you run high-volume production runs or complex multi-operation machining, the KSZ115 is designed to keep your spindle cutting and your downtime at an absolute minimum.

Constructed from premium stainless steel, this system is built to withstand the rigors of industrial machining environments — resistant to coolant, chips, and the mechanical stresses of repeated clamping cycles. The zero-point clamping principle ensures your workpiece returns to the exact same position every single time, dramatically reducing setup times and improving part-to-part consistency.

Made in Mainland China.

Key Features

• True Zero-Point Precision: Sub-micron repeatability for consistent, accurate positioning every time a pallet is loaded.
• Heavy-Duty Stainless Steel Construction: Corrosion-resistant and built to endure demanding machining environments with high clamping forces.
• Quick-Change Pallet System: Dramatically reduces machine downtime — swap pallets in seconds rather than minutes.
• Universal Compatibility: Designed for use with CNC machining centers, milling machines, grinding machines, and EDM equipment.
• High Clamping Force: Delivers robust and secure workholding to support aggressive cutting parameters and high-speed machining.
• Hydraulic/Pneumatic Ready: Compatible with pneumatic or hydraulic actuation for automated and semi-automated production lines.
• Reduced Setup Time: Streamlines your workflow by enabling pre-staged pallets to be loaded offline while the machine continues to run.
• Improved Productivity: Less time setting up means more time cutting — ideal for job shops and high-volume production facilities alike.

Specifications

• Model: KSZ115
• Material: Stainless Steel
• Type: Zero-Point Quick-Change Clamping System
• Application: CNC Machining Centers, Milling, Grinding, EDM
• Origin: Made in Mainland China

Why Choose a Zero-Point Clamping System?

Zero-point clamping systems are the industry standard for modern, efficient CNC production. By establishing a fixed, repeatable datum point, machinists can eliminate the need to re-indicate and re-datum workpieces between operations. This translates directly into reduced non-cutting time, fewer setup errors, and superior part quality. For more on precision workholding and manufacturing best practices, visit NIST Manufacturing Resources.

Related Products You May Like

• 1/4" Hex Wire Twister Drill Attachment – Rebar Tie Wire Tool
• 1/4" & 3/8" to M4–M10 Thread Conversion Screw Mount Adapter

Frequently Asked Questions

Q: What is a zero-point clamping system and how does it work for CNC machining centers?

A: A zero-point clamping system is a precision workholding solution that uses a fixed reference datum (the "zero point") machined into both the pallet and the receiver unit. When a pallet is loaded, it locks into this datum with extremely high repeatability — often within a few microns. This means operators can pre-stage workpieces on pallets offline, then swap them onto the machine table in seconds without re-indicating or re-zeroing, saving significant setup time between operations.

Q: Is the KSZ115 compatible with my existing CNC machine?

A: The KSZ115 zero-point clamping system is designed for broad compatibility with CNC machining centers, milling machines, grinding machines, and EDM equipment. It is suitable for machines that support pneumatic or hydraulic actuation. We recommend verifying your machine's table specifications and actuation port availability before ordering to ensure a seamless integration.

Q: What material is the KSZ115 made from, and is it suitable for wet coolant environments?

A: The KSZ115 is constructed from high-grade stainless steel, making it naturally resistant to coolant, cutting fluids, and corrosion. It is specifically engineered for use in demanding industrial machining environments where exposure to coolants and metal chips is routine.

Q: How much does using the KSZ115 quick-change pallet system reduce my setup time?

A: In typical CNC production environments, traditional workpiece setup can take anywhere from 15 minutes to over an hour per part or batch. A zero-point quick-change pallet system like the KSZ115 can reduce that changeover time to under a minute for each pallet swap, since datum alignment is built into the system. The exact time savings will depend on your specific workflow, part complexity, and the number of operations involved.
