SMA905 Metal Fiber Optic Cable — 600µm Core | 200–1100nm Broadband

Precision-engineered for laboratory and industrial spectroscopy, the SMA905 Metal Fiber Optic Cable delivers reliable light transmission across an exceptionally wide 200–1100nm wavelength range — covering UV, visible, and near-infrared (NIR) spectra in a single robust assembly. With a 600µm core diameter and a durable all-metal SMA905 connector housing, this fiber cable is built for demanding optical setups where consistency and signal integrity matter most.

Key Features

Wide Wavelength Range: 200–1100nm — suitable for UV, VIS, and NIR applications including spectrometry, laser coupling, and optical sensing
Large 600µm Core Diameter: Maximizes light throughput and makes alignment easier in experimental and OEM setups
SMA905 Stainless Steel Connector: Industry-standard metal connector ensures secure, repeatable coupling to compatible spectrometers, light sources, and accessories
0.55m Cable Length: Practical working length ideal for benchtop instruments and short-run light delivery
Passive, Non-Electrified Design: Purely optical — no electrical components, safe to use in sensitive measurement environments
No High-Concern Chemicals: Clean, lab-safe construction with no hazardous chemical content
Durable Metal Jacket: Protects the fiber from mechanical stress, bending fatigue, and environmental interference

Typical Applications

UV-VIS-NIR spectroscopy and spectrometer light coupling
Laser beam delivery and fiber coupling
Optical sensing and fluorescence measurement
Laboratory light source-to-sample illumination
OEM optical instrument integration
Remote sensing and process monitoring

Technical Specifications

Connector Type	SMA905 (Metal)
Core Diameter	600µm
Cable Length	0.55m
Wavelength Range	200–1100nm (UV–VIS–NIR)
Electrified	No
High-Concern Chemicals	None
Country of Origin	Made in Mainland China

Related Products You May Need

For more on fiber optic technology standards and applications, visit the NIST Photonics & Fiber Optics Resource.

Learn more: Fiber-optic cable

Frequently Asked Questions

Q: What instruments are compatible with the SMA905 fiber optic cable?

A: This SMA905 metal fiber cable is compatible with any instrument featuring a standard SMA905 port — including most UV-VIS-NIR spectrometers, broadband light sources, laser modules, and optical probes. It is widely used in laboratory, OEM, and industrial measurement setups.

Q: What does the 600µm core diameter mean for performance?

A: A 600µm core diameter is considered large in optical fiber terms, which means it collects and transmits significantly more light than smaller-core fibers. This makes it ideal for applications requiring high light throughput, such as fluorescence spectroscopy, absorbance measurements, and illumination tasks where maximizing signal is critical.

Q: Can this fiber cable handle UV wavelengths without degradation?

A: Yes. The 200–1100nm wavelength range specifically includes deep UV (down to 200nm), making this cable suitable for UV spectroscopy and UV laser delivery. The fiber material and metal connector housing are selected to withstand UV exposure in typical laboratory use conditions.

Q: Is the 0.55m length fixed, or are other lengths available?

A: This listing is for the 0.55m length version of the SMA905 600µm fiber cable. This length is ideal for benchtop and compact instrument setups. If you require a different cable length for your specific application, please contact us for availability.
