Stepper Motor Controller Module – PWM Pulse Signal 12-24V

Stepper Motor Drive Controller Module – PWM & Pulse Signal Generator

Take precise control of your stepper motor system with this compact and versatile Stepper Motor Drive Controller Module. Designed for makers, engineers, and electronics hobbyists, this module generates both PWM and pulse signals, supports clockwise and counterclockwise rotation, and offers three selectable frequency ranges — all in a small, easy-to-integrate form factor. Simply combine it with a stepper driver, stepper motor, and a DC power supply for a complete, functional motion control platform.

Made in Mainland China.

Key Features

• User-Friendly Design: Simple controls make it easy to manage speed, direction, and signal generation for your stepper motor — no complex programming required.
• Wide Input Voltage Range: Accepts 8–24V DC input, making it compatible with a broad range of power supplies and project setups.
• Three Selectable Frequency Ranges: Switch between High (5.4kHz–160kHz), Medium (540Hz–16.6kHz), and Low (80Hz–2.4kHz) frequency bands via jumper selection to match your application needs.
• PWM & Pulse Signal Output: Easily toggle between PWM and pure pulse signal output using onboard jumper wires for maximum versatility.
• Bidirectional Rotation Control: Switch effortlessly between clockwise and counterclockwise rotation to give you full directional control over your motor.
• Compact Form Factor: At just 58 × 51 × 13 mm (2.28 × 2.01 × 0.51 in), this module fits neatly into space-constrained enclosures and DIY builds.

Technical Specifications

What's in the Box

• 1 × Stepper Motor Controller Board

Important Notes

This module is a pulse/PWM signal generator only — it does not include a stepper driver. To drive a stepper motor, you will need to pair this board with a compatible stepper motor driver, stepper motor, and DC power supply. Colors may appear slightly different from pictures due to monitor settings. Please allow ±1–2 cm measurement tolerance.
