Voltage Converter Regulator DC-DC 12V 10V-18V Step-up 48V 10A 480W
$81.92
Sale price
$81.92
Regular price
$101.49
Shipping calculated at checkout.
Discover the Voltage Converter Regulator DC-DC 12V 10V-18V Step-up 48V 10A 480W — a standout decor pick featuring waterproof, compact design for dependable, everyday performance.
Specifications
Brand Name: kangwobei
Certification: CE,RoHS
Model Number: WH-12-24 ,WH-30-57
Protections: Over-load, Over-current, Over-temperature, Short-circuit, Over-voltage.
Type: DC/DC Converters
Product Description
1. 100% full power and stable current output, non-isolated module.
2. Waterproof level IP68 and anti-shock protection, Ultra compact size, light weight.
3. Industry grade DC12V to DC 48V step-up converter, efficiency up to 95%.
4. Die-cast aluminum shell, epoxy potting, cooling by free air convection.
5. 1 year warranty, lifetime up to 100,000 hours.
6. Protections: Over-current, Over-voltage, Over-temperature, Over-load and Short-circuit, auto-recovery when device is back to normal operating.
Specifications:
* Input Rated Voltage: DC 12V
* Input Voltage Range: 10V-18V DC
* Output voltage: DC 48V 10A
* Output Rated Power: 480W
* Efficiency: 95% (half load); 94% (full load)
* Output Peak Power: 600W
* Voltage Regulation: Less Than 1%
* Load Regulation: Less Than 2%
* Ripple(full load test): Less Than 150mV
* No-load Current: 25mA
* Total Size: 150*127*63mm(L*W*H)
Package included:
1 x DC 12V to DC 48V Voltage Converter
Options
- Color: 24V to 48V 3.5A, 12V to 48V 15A, 24V to 48V 15A, 12V to 48V 3.5A
