ALLOYSEED YF-7 Dual-Channel Delay Relay Module – 32 Functions

ALLOYSEED YF-7 Multifunctional Dual-Channel Delay Relay Module

Take full control of your electronics projects with the ALLOYSEED YF-7 Dual-Channel Delay Relay Module. Packed with 32 programmable functions, this versatile timer relay board is perfect for DIY engineers, hobbyists, and automation enthusiasts who need precise, reliable trigger and delay control. Whether you're managing solenoid valves, water pumps, motors, or LED light strips, the YF-7 delivers repeatable performance with a wide adjustable time range of 0.01 seconds to 999 minutes.

Made in Mainland China.

Key Features

• Dual Independent Channels: Signal 1 controls Relay 1; Signal 2 controls Relay 2 — they operate simultaneously yet completely independently.
• Wide Input Voltage Range: DC 7V–30V, making it compatible with most hobby and industrial power supplies.
• 32 Programmable Functions (P-11 to P-48): Covers jog, self-lock, pulse trigger, cycle timer, countdown, power-on delay, and much more.
• Adjustable Time Range: From 0.01 seconds to 999 minutes — any duration, fully customizable.
• 5A Load Capacity: Safely controls both DC and AC loads up to 5A, including motors, pumps, valves, and lighting.
• Non-Volatile Memory: All parameters for functions P-11 through P-44 are retained after power-off, so your settings are never lost.
• Comprehensive Manual Included: Clear wiring descriptions and full function list so you can get started right away.

Technical Specifications

Wiring Port Guide

• + — Input power positive
• – — Input power negative
• IN+ — Positive signal input terminal
• IN– — Negative signal input terminal
• NO — Relay normally open interface (open before trigger, closed after trigger)
• COM — Relay common interface
• NC — Relay normally closed interface (closed before trigger, open after trigger)

Common Applications

• Automated water pump and solenoid valve control
• Motor start/stop timing sequences
• LED and light strip pulse/cycle control
• Industrial and home automation projects
• DIY electronics and Arduino/microcontroller integration

What's in the Box?

• 1 × YF-7 Dual-Channel Delay Relay Module Board
